Laboratory Gas Generator

99.999% High Purity PEM Hydrogen Generator For GC Laboratory Application Pressure 0-4 Bar

All Category

Industrial Hydrogen Generation System

Large Electrolysis Cell Stack

Complete Hydrogen Generation System

Laboratory Gas Generator

Electrolysis Cell Stack

PEM Hydrogen Generator

Alkaline Hydrogen Generator

Air and Nitrogen

Air Series

Nitrogen Series

Combined Generator

VOC Online Generator

Zero-Air Purifier

Hydrogen Inhalator

Hydrogen Inhalation Machine

Hydrogen Oxygen Inhalation Machine

Others

Mr. Rick Hu

success-rick@ql-spe.com

+86 13305312544

Contact Now

99.999% High Purity PEM Hydrogen Generator For GC Laboratory Application Pressure 0-4 Bar

Brand Name:	Saikesaisi
Price:	$1,200.00/sets 1-4 sets
Packaging Details:	wooden box package

Detail Information

Product Description

Detail Information

Place of Origin:

Shandong, China

Certification:

CE/ISO9001, CE/ISO 9001

Production Rate:

99.999% Purity

Weight:

15KG

Dimension(L*W*H):

420x230x352mm

Warranty Of Core Components:

1 Year

Model:

QL-300

Purity:

99.999%

H2 Flow Rate::

0-300ml/min

Pressure:

0-4 Bar

Power Supply:

100~120V Or 200-240V

After-sales Service Provided:

Provided Service Online, Video Technical Support, Free Spare Parts, Online Support

Technology:

PEM

MOQ:

1 Unit

Warranty Time:

12 Months

Local Service Location:

None

Showroom Location:

None

Condition:

New

Use:

HYDROGEN

Warranty:

1 Year

Key Selling Points:

PEM Electrolysis Cell

Marketing Type:

Hot Product 2019

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Applicable Industries:

Manufacturing Plant, Laboratory Application

Core Components:

Electrolysis Cell

Voltage:

100-120V Or 200-240V

Highlight:

99.999 PEM Hydrogen Generator

PEM Hydrogen Generator for GC

hydrogen generator laboratory

Product Description

99.999% High Purity PEM Hydrogen Generator for GC in Lab Application Pressure 0-4 Bar

QL-300, producing highly pure hydrogen gas by utilizing SPE technology to electrolyze pure water (no adding alkali), are light highly effective, energy-saving and environmental protection.

Specifications:

1. 0~310 ml/min flow hydrogen generator

2. H2 purity :99.999%

3. PEM technology .

4. CE certification. Own patent right.

Technical Parameter:

Type	QL-300
Output Volume (ml/min)	0~310
Output Pressure (MPa)	0.02~0.4
Pluctuation Rate of Output Pressure(%)	<0.2
H2 purity (%)	>99.999
Second Protective Pressure (MPa)	0.46
Power Voltage (V)	220±15% 110±15% 50~60Hz
Input power (W)	<150
Dimension (LxWxH) mm	431x228x343
Gross Weight (KG)	< 15

Structural characteristics of the Products:

Distance between anode and cathode is close to zero, and highly active SPE catalytic electrodes are used.
Plural-electrode and multiunit electrolysis cell structure with excellent chemical technological process properties of the mass and heat transfer.
Best choice of materials for multi-electrode and pluralist electrolysis cell with excellent properties of electrochemistry, anti-corrosion and bearing deactivation.

Functions and Characteristics of the Products:

Electrolysis of pure water (adding no alkali) to produce hydrogen with no corrosion and pollution, and the purity of hydrogen is extremely high.
Voltage of unit cell is low, and electric resistance in the electrolysis cell is little, giving out no heat, and cycle of changing desiccants is long, producing highly pure hydrogen.
With stable pressure and output, Hydrogen is controlled according to the requirements, and automatic control technology is perfect and reliable.
Power consumption is less, and the electrolysis is efficient.

Applied Area:

The small-sized products (QL-150/300/500) are ideal equipment for gas chromatographs and optical fiber sintering. The products can absolutely take the place of steel cylinders of hydrogen, and can be used safely and conveniently.
Used for fuel cell.
Supply hydrogen for metal hydride.
Others application: reduction protection ,purification of materials , Metal welding and smelting, fire fiber optic, surface protection , Used for cars or truck

99.999% High Purity PEM Hydrogen Generator For GC Laboratory Application Pressure 0-4 Bar 0

99.999% High Purity PEM Hydrogen Generator For GC Laboratory Application Pressure 0-4 Bar 2
